| Starting: |
Electrical start |
Drive Train: |
Chain drive |
| Engine Type: |
GY6 150㎝3 |
Max. Torque: |
9.3N.m/5500r/min |
| Clutch method: |
CVT |
Shift Method: |
Hand Gear |
| N.W. (Kg) |
220Kg |
Loading weight:(Kg) |
≤150 Kg |
| G.W.(Kg) |
270Kg |
Ground Clearance:mm |
150mm |
| Max. Speed:(Km/h) |
55Km/h |
Overall Size (H) |
1380mm |
| Overall Size (L) |
2270mm |
Overall Size (W) |
1520mm |
| Seat Height:(H) |
420 mm |
Steering wheel Diameter : (B2) |
305mm |
| Wheelbase:(L1) |
1792mm |
Turning Circle Radius (mm) |
3700mm |
| Tires/Front: |
19×7-8 |
Tires/Rear: |
18×9.5-8 |
| Reliability: |
2500Km |
Durability: |
5000Km |
| Suspension/Front: |
385mm±2 |
Suspension/Rear: |
470mm±2 |
| Braking force/Front: |
≥450N |
Braking force/Rear: |
≥500N |
| Fuel Capacity: |
6L |
Speed limited:（yes/no） |
yes |
| Emission: |
CO≤3.8％ HC≤800ppm |
Starting Time: |
≤15s |
| Side slip |
≤±5m/km |
Brake Distance: |
30km/h≤7m |
| Flame out Switch（yes/no） |
yes |
Remote:（yes/no） |
no |
| Starting Acceleration Capability: |
(0～200m)≤15s |
Max Noise: |
≤80dB |
| Passing Acceleration Capability: |
(200m/30km/h) ≤14s |
Climbing degree: |
≤200 |
| Packing size(mm) |
2310×1170×660 mm |
Carton size:(mm) |
2310×1170×600mm |
| Loading qty（40HQ） |
40pcs |
Battery: |
12V 9AH |
| Front and rear braking method |
Foot brake |
|
|
