| ENGINE | |
| Minimum Age | 10 Years Old |
| Engine Type | 4-stroke, air-cooled single cylinder |
| Transmission gears | Fully Automatic with D-N-R |
| Transmission | Chain Drive |
| Gear Selector Lever | Hand |
| Fuel Delivery | Carburetor |
| Ignition | CDI |
| Start | Electric only |
| Fuel Tank Capacity | 2.3L / 0.60 US GAL |
| CHASSIS | |
| Front Suspension Type | Dual A-Arm, 12.4″ travel |
| Rear Suspension Type | Mono Swingarm, 12.4″ travel |
| Front Brake | Disc |
| Rear Brake | Disc |
| Front Tire | 19×7-8 |
| Rear Tire | 18×9.5-8 |
| Wheel Type | Steel |
| Remote Wireless Shut Off | Yes |
| Speed Limiter | Yes |
| Tether Kill Switch | Yes |
| Battery | 12V/5AH |
| Front Lights | LED |
| Brake Light | LED |
| DIMENSION | |
| Seat Height | 26 Inches |
| Ground Clearence | 4 Inches |
| Wheel Base | 38 Inches |
| Estimated Dry Weight | 264 lbs. |
| Overall Dimensions (LxWxH) | 59″x38.5″x38″ |
| Warranty | 6 months |
Shop
COYOTE 125
- WIRELESS ENGINE SHUT OFF: The Coyote 125 comes with a unique Wireless Engine Shut Off key fob, giving the supervising adult an extra level of control. A simple push of the shut-off button will turn the engine off and the Coyote 125 coasts to a stop. When the child has corrected him- or herself, the adult can push the remote start to restart the engine for them.
- GREASE ZERKS: Proper maintenance isn’t just for adult-sized units. The TrailHawk has grease zerks in key high wear areas. Easy access points let you teach your young rider to do his or her own maintenance right from the beginning.
- WHEELS: The Coyote 125 has 8-inch wheels that deliver excellent traction and performance across a wide variety of terrain, while also enhancing ride quality.
- Electric Start Engine: The air-cooled, SOHC four-stroke engine is built tough to deliver fun for years. The smooth-running power plant features a convenient electric start and has a unique Wireless Engine Shut Off key fob for parents’ peace of mind.
- LED Running Lights: Style and safety go hand in hand on the Coyote 125. Cool LED front running lights to help keep the TrailHawk visible when your young rider is adventuring around your property. The rear brake lights are also high visibility LEDs.
