Item No |
Snowfox Ⅱ |
Engine type |
GY6 170cc |
Max power/RPM(kw/r/min) |
7.6/7000 |
Max torque/RPM(N.m/r/min) |
10.2/5000 |
Fuel consumption |
5.5L/100km |
Tank capacity |
4.5L |
Culth |
Automatic |
Supply sustem |
Carburetor |
Brake control(rear) |
Hand control |
Way of drive |
Chain and rubber track drive |
Start type |
Electrical and hand start |
Max speed |
45-50km/h |
Overall size (L*H*W) |
2500*950*1150mm |
Dry weight |
130kg |
Load,Max |
170kg |
Brake system (rear) |
Disc brake |
Climb ability |
30°-35° |
Caterpillar band overall length |
2150mm |
Caterpillar band width |
380mm |
Press snow deepth |
5-8cm |
Press snow length |
880mm |
Skid L*W |
920×150mm |
Loading capacity |
30pcs/20’GP 83pcs/40’HQ |
