Item No Snowfox
Engine type GY6 170cc
Max power/RPM(kw/r/min) 7.6/7000
Max torque/RPM(N.m/r/min) 10.2/5000
Fuel consumption 5.5L/100km
Tank capacity 4.5L
Culth Automatic
Supply sustem Carburetor
Brake control(rear) Hand control
Way of drive Chain and rubber track drive
Start type Electrical and hand start
Max speed 45-50km/h
Overall size (L*H*W) 2400*980*1140mm
Dry weight 170kg
Load,Max 170kg
Brake system (rear) Disc brake
Climb ability 30°-35°
Caterpillar band overall length 2400mm
Caterpillar band width 310mm
Press snow deepth 5-8cm
Press snow length 880mm
Skid L*W 920×135mm
Loading capacity 16pcs/20’GP   54pcs/40’HQ
