| Model |
DB20 |
| ENGINE Type: |
70cc, Air cooled, 4-stroke, 1-cylinder |
| Bore×Stroke: |
φ47*41.4mm |
| Compression Ratio: |
8.8:1 |
| Carburetor: |
PZ19 |
| Ignition: |
CDI |
| Starting: |
Electrical start |
| Transmission: |
Automatic |
| Drive Train: |
Chain drive |
| Max. Power: |
3.7kw/7500r/min |
| Max. Torque: |
4.5Nm/5500r/min |
| Suspension/Front: |
Double shock absorber |
| Suspension/Rear: |
Single shock absorber |
| Brakes/Front: |
Ventilated Hydraulic disc |
| Brakes/Rear: |
Ventilated Hydraulic disc |
| Max Speed : |
50km/h |
| Tires/Front: |
2.75-10 |
| Tires/Rear: |
2.75-10 |
| Overall Size (L*W*H) |
1370×630×840mm |
| Seat Height: |
620mm |
| Wheelbase: |
970mm |
| Ground Clearance: |
160mm |
| Battery: |
12V5Ah |
| Fuel Capacity: |
4L |
| Dry Weight: |
55kg |
| Max. Load: |
70kg |
| Package Size: |
1190×345×630mm |
| Loading Quantity: |
84pcs/20´GP, 256 pcs/40´HQ |
